Strength training

T130

VBT System

Measure the rep. Review the set.

Connected rep-by-rep velocity-based training monitoring.

Request T130 specsDiscuss your setup
Kinedge T130 right front three-quarter product view
Original no-logo product render

At a glance

Measure the rep. Review the set.

Connected rep-by-rep velocity-based training monitoring.
010-2.7 mMeasurement range
020.1 mmDistance resolution
031,000 HzSampling frequency
0415 hContinuous operation
053.3 kgDevice weight
06BluetoothDevice communication

Purpose and output

What it does.

Rep-by-rep training monitoring · Strength-power testing · Session review and rep comparison

What it measures.

Position · Velocity · Force · Power · Peak velocity · Average velocity

One product. One continuous session.

From device
to decision.

The Kinedge manual confirms Bluetooth pairing with the Kinedge App, live curves and rep feedback, history, and cloud data processing.
Kinedge T130 right front three-quarter product view
T130
Kinedge App live training screen in English
Kinedge App
03Cloud
session
Kinedge admin console overview in English
Admin console
  1. 01CaptureT130
  2. 02Coach liveKinedge App
  3. 03SyncCloud session
  4. 04OperateAdmin console
  5. 05DecideReturn to training

Verified detail

Scan the facts.
Open the detail.

Only fields confirmed in the named source document are shown.

01Performance / Measurement
Measurement range0-2.7 m
Distance resolution0.1 mm
Sampling frequency1,000 Hz
Displayed dataPosition / Velocity / Force / Power
02Physical
Dimensions260 x 141.5 x 119 mm, tolerance +/-5 mm
Weight3.3 kg, tolerance +/-0.3 kg
Rotation angle-15 degrees to 64 degrees
03Electrical
Continuous operation15 h
Operating voltage24 V
Charging input100-240 V
Charging frequency50-60 Hz
Battery3,200 mAh rechargeable lithium battery
04Connectivity
CommunicationBluetooth
Operation panelStandard tablet
Companion softwareKinedge App
Source record
  • Kinedge VBT T130 User Manual (English) — Kinedge
